Wakepotentials in the plane x=0 and y=0

Up: Looking at the wakepotentials Previous: Looking at the wakepotentials

We can look at the wakepotentials in any plane x=x0, y=y0. When we want to look at the wakepotentials in the planes x=0 and y=0, we specify

 watxi = 0
 wxatxi= 0
 wyatxi= 0

 watyi = 0
 wxatyi= 0
 wyatyi= 0

 doit

The resulting plots are shown in the figures 10.6 and 10.7

**Figure 10.6:** Screenshot of the desktop showing the longitudinal and transverse wakepotential near the plane x=0.
$\begin{figure}\centerline{ \psfig{figure=3d-wakepotentials02.PS,width=608pt} }\end{figure}$

**Figure 10.7:** Screenshot of the desktop showing the longitudinal and transverse wakepotential near the plane y=0.
$\begin{figure}\centerline{ \psfig{figure=3d-wakepotentials03.PS,width=608pt} }\end{figure}$

This is the end of this tutorial.
